Drawtube Activated

CPC Power Collet Chuck Features The CPC Power Collet Chuck is the most popular model for CNC Lathe power workholding solution. The CPC Power Collet Chuck works with DIN6343 or C-44 type spring collets. Besieds O.D. chucking, CPC Collet Chuck (CPC-44) can be converted into I.D. expanding chuck by installing a push nut and a expanding mandrel. Precision dead-length collet chuck: 0.025mm repeatability. Large clamping force. Work with DIN6343 collets: 163E(B30), 173E(B42), 185E(B60), 193E(B80). Work with C-44 collet or C-44I expanding kit.. High speed up to 8000RPM (CPC-30). Large through hole up to 80mm (CPC-80). I.D. chucking possible by installing an expanding mandrel and a push nut. (CPC-44)      Ordering of Expanding Kit for CPC-44 The CPC-44 Collet Chuck can also be converted to an I.D. expanding chuck by installing a pushing nut and an expanding mandrel. The conversion is very easy. Please inform JATO the dimension of the mandrel, or send us the drawing of your work-part. The mandrel will be quick shipped in 10 days.
