| Product | Chuck Size Ø mm |
Through Hole Ø mm (Standard) |
Jaw Stroke Ø mm (Standard) |
Rotational Speed (rpm) |
Weight Kg |
Spindle Mounting |
|
|---|---|---|---|---|---|---|---|
| PULL LOCK POWER CHUCK AG-3D-04 | 110.0 | 0.0 | 5.0 | 3500 | 4.5 | Adaptor Recess Mount Ø85mm h6 | More Info |
| PULL LOCK POWER CHUCK AG-3D-05 | 135.0 | 0.0 | 5.0 | 3500 | 7.9 | Adaptor Recess Mount Ø110mm h6 | More Info |
| PULL LOCK POWER CHUCK AG-3D-06 | 165.0 | 0.0 | 7.2 | 3500 | 15.0 | Adaptor Recess Mount Ø140mm h6 | More Info |
| PULL LOCK POWER CHUCK AG-3D-08 | 210.0 | 0.0 | 7.2 | 3000 | 26.0 | Adaptor Recess Mount Ø170mm h6 | More Info |
| PULL LOCK POWER CHUCK AG-3D-10 | 254.0 | 0.0 | 10.8 | 2500 | 46.0 | Adaptor Recess Mount Ø220mm h6 | More Info |
| PULL LOCK POWER CHUCK AG-3D-12 | 304.0 | 0.0 | 10.8 | 2000 | 70.0 | Adaptor Recess Mount Ø220mm h6 | More Info |
| PULL LOCK POWER CHUCK AG-3D-215 | 381.0 | 0.0 | 14.5 | 1500 | 132.0 | Adaptor Recess Mount Ø300mm h6 | More Info |
